Solid mahogany (not a multi-ply!) arch top body
High quality flame Canadian maple top (100% genuine wood top - not a photo top!)
Triple bound body and headstock
Single binding on neck
Graph Tech NVS2 bridge with string saver saddles
Improved nickel plate hardware, including nickel die-cast Grover tuners with 18-1 turning ratio for ultra fine tuning (Model 102-18N)
Two Type V Alnico humbucker pickups for that warm, traditional sound
The AL-3100 comes with improved wiring, improved pots (now higher voltage with brass shafts for reduced noise), and an improved pickup selector switch
Two volume controls, two tone controls, plus a three way pickup selector switch
One piece mahogany set neck with 13.7" (350mm) radius neck for fast play and adjustable truss rod
Ebony fretboard with 22 jumbo frets and Mother of Pearl trapezoid inlays
The AL-3100 features D'addario strings installed at the factory and a professionally installed Graph Tech nut
Individually hand filed frets for professional feel and playability
Measurements
Overall length: 40"
Scale length: 24 3/4"
Width at the widest point: 13"
Width of the neck at the nut: 1 11/16" (42.8mm)
Width of the neck at the 21st fret: 2 3/16" (56mm)
Neck taper (thickness) at the 1st fret: 3/4" (19.5 mm)
Neck taper (thickness) at the 12th fret: 7/8" (22mm)
Body thickness at edge: 2"
Weight: only 10 pounds
Wiring Diagram
|
Your final shipping costs will depend on your location and the items you order. To determine your total shipping cost, please click on the “add to shopping cart” button, and enter your address information. You will have the opportunity to cancel your order after you are quoted a shipping price.
$425.00
|
|
|
